React Components on Stream Deck Hardware

The official @elgato/streamdeck SDK is powerful but low-level. You track state manually, wire hardware events by hand, and generate key images yourself. Even a simple counter becomes a mix of event handlers, state bookkeeping, and rendering code. I wanted the same model I use in React apps — declare what the key looks like, let the framework handle the rest. So I built @fcannizzaro/streamdeck-react.

How it works

You write a React component for each action surface. defineAction() maps it to a manifest UUID. createPlugin() registers your actions and fonts, then plugin.connect() attaches to the Stream Deck runtime.

Each visible action instance on the hardware gets its own isolated React root — separate state, separate lifecycle. When state changes trigger a re-render, the library renders the JSX tree to an image via the native Takumi renderer and pushes it to the device. A 4-phase skip hierarchy prevents redundant work at every step.

Counter example

import { createPlugin, defineAction, useKeyDown, cn, googleFont } from '@fcannizzaro/streamdeck-react';
import { useState } from 'react';

function CounterKey() {
  const [count, setCount] = useState(0);

  useKeyDown(() => setCount((c) => c + 1));

  return (
    <div
      className={cn(
        'flex h-full w-full flex-col items-center justify-center gap-1',
        'bg-linear-to-br from-[#0f172a] to-[#1d4ed8]',
      )}
    >
      <span className="text-[12px] font-semibold uppercase tracking-[0.2em] text-white/70">
        Count
      </span>
      <span className="text-[34px] font-black text-white">{count}</span>
    </div>
  );
}

const counterAction = defineAction({
  uuid: 'com.example.react-counter.counter',
  key: CounterKey,
  info: {
    name: 'Counter',
    icon: 'imgs/actions/counter',
  },
});

const plugin = createPlugin({
  fonts: [await googleFont('Inter')],
  actions: [counterAction],
});

await plugin.connect();

defineAction() accepts an info field that drives automatic manifest.json generation at build time — no hand-written manifest needed. The googleFont() helper downloads and caches the font from Google Fonts.

Rendering pipeline

The rendering pipeline is built around minimizing redundant work. Every render attempt passes through four phases before anything reaches the hardware:

1. Dirty-flag check — O(1) boolean check on the container root. If no VNode was mutated since the last flush, the entire render is skipped.
2. Merkle-tree hash + image cache — a structural hash of the VNode tree is compared against a byte-bounded LRU cache. Unchanged subtrees reuse cached hashes, so a single-node mutation only rehashes O(depth) nodes.
3. Takumi render — the VNode tree is converted directly to Takumi nodes (bypassing React.createElement) and rasterized by the native Rust renderer. This can run on a worker thread to keep the main thread free for event handling.
4. xxHash output dedup — the raw pixel buffer is hashed via xxHash-wasm. If it matches the previous frame, encoding and the hardware push are skipped entirely.

On top of this, an adaptive debounce detects whether a root is animating (0ms delay), interactive (16ms), or idle (configurable), and a flush coordinator with four priority levels ensures animated and interactive keys get first access to the USB bus.

What you get

Hooks

• Event hooks — useKeyDown, useKeyUp, useDialRotate, useDialPress, useTouchTap and more for direct hardware input
• Gesture hooks — useTap, useLongPress, useDoubleTap for higher-level input handling on keys and touch surfaces
• Animation hooks — useSpring (physics-based damped harmonic oscillator) and useTween (duration/easing) for smooth value transitions, with built-in presets like wobbly, stiff, gentle, and snap
• Settings hooks — useSettings and useGlobalSettings for per-action and plugin-wide persistent state, synced with the Property Inspector
• Coordinator hooks — useChannel for cross-action shared state and useActionPresence for tracking which actions are currently visible
• TouchStrip hooks — useTouchStrip for rendering across the full-width Stream Deck+ touch display
• Lifecycle hooks — useWillAppear, useWillDisappear for mount/unmount logic
• SDK hooks — useStreamDeck, useAction, useDevice for accessing the underlying SDK

Components

• Layout primitives — Box, Text, Image, Icon for building compact UIs on tiny displays
• Data visualization — ProgressBar and CircularGauge for status indicators
• Error handling — ErrorBoundary wraps every action root automatically, one crash doesn’t take down the plugin

Styling

• Tailwind CSS — cn() helper for Tailwind-like utility strings, with full Tailwind v4 support via compiled stylesheets
• CSS Theme System — defineTheme() for centralized design tokens as CSS custom properties, with runtime switching via useTheme() and composable theme merging via mergeThemes()

Architecture

• One root per instance — each visible action gets its own isolated React root with separate state, settings, and lifecycle
• Root recycling — dormant roots are pooled and reused on profile switches, reducing latency from ~15ms to ~3ms per key
• Manifest auto-generation — defineAction({ info }) metadata is extracted via AST analysis at build time to generate manifest.json
• Shared state — Zustand, Jotai, and React Query plug in through the wrapper API on createPlugin or defineAction
• DevTools — browser-based inspector for debugging layouts, state, and render performance
• React Compiler — optional integration via Babel plugin to automatically optimize re-renders
• Agent Skill — installable AI skill that teaches coding agents the full API surface for assisted plugin development

Real-world use case: HoYo Deck

HoYo Deck is a free Stream Deck plugin I built with streamdeck-react for HoYoverse games (Genshin Impact, Honkai: Star Rail, Zenless Zone Zero). It tracks stamina, banners, endgame progress, daily rewards, and more — with full support for Stream Deck+ dials and touch displays.

It exercises most of the library’s features in production:

• Animated gauges — resin, trailblaze power, and battery charge use circular gauges with spring animations
• Shared state via coordinator — the stamina overview dial action shows up to three games side-by-side, sharing data across actions with useChannel
• Settings sync — HoYoLAB account credentials and per-game toggles are managed through useSettings with a custom Property Inspector
• TouchStrip rendering — the stamina overview renders a full-width layout across the Stream Deck+ touch display
• Encoder support — the wish tracker uses dial rotation to increment a pity counter, press for +10, tap to reset

If you’re curious, the source is on GitHub and the plugin is free on the Elgato Marketplace.

Get started

bun create streamdeck-react

The CLI scaffolds a complete .sdPlugin project — manifest, bundler config (Vite with Rolldown), fonts, and a starter example. Pick from minimal, counter, Zustand, Jotai, or Pokemon (React Query) templates.

For manual setup:

bun add @fcannizzaro/streamdeck-react react

Full documentation at streamdeckreact.fcannizzaro.com. Source on GitHub. Package on npm.
